Harder & Steenbeck Evolution 2024 Airbrush Parts

0.28 mm & 0.45 mm Evolution 2024 Headsets

The Evolution 2024 platform supports 0.28 mm and 0.45 mm FineLine configurations, allowing painters to select a setup based on the amount of detail, paint flow, and coverage required.

• 0.28 mm headset: Suited to controlled detail work, gradients, shading, fine lines, and precision-oriented painting.
• 0.45 mm headset: Provides increased paint flow for general-purpose painting, base coating, larger surfaces, and broader spray applications.
• Complete headset assemblies: Coordinated nozzle, needle, air cap, and sealing components help maintain the correct front-end configuration.

Evolution 2024 Needles, Nozzles & Air Caps

Needles, nozzles, and air caps are precision components that directly affect paint delivery and spray characteristics. When replacing one of these parts, match it to the corresponding Evolution 2024 headset size.

• Replacement needles: Available for the corresponding detail and general-purpose configurations.
• Replacement nozzles: Match the nozzle to the correct needle and FineLine air-cap system.
• FineLine air caps: Available in model-specific configurations for the Evolution 2024 front end.
• Needle caps: Replacement protective components are available for the Evolution 2024 headset system.

Seals, Air Valves & Service Components

Internal seals and air-system components help maintain proper airflow, paint isolation, and reliable trigger operation. Worn or damaged parts can be replaced individually or through compatible service kits.

• Seal kits: Model-specific sealing components for Evolution 2024 maintenance.
• PTFE needle seals: Help seal the paint passage around the needle.
• Air valve components: Complete assemblies and compatible service parts are available for maintaining airflow control.
• O-rings and nozzle seals: Small replacement components help maintain proper fit and sealing between precision parts.

Triggers, Springs & Needle Control Parts

The Evolution 2024 trigger system uses several components that work together to control airflow, needle movement, and paint delivery. Replacement parts are available when servicing or rebuilding this mechanism.

• Trigger assemblies: Replacement trigger components for maintaining smooth double-action control.
• Needle springs: Support consistent needle return during trigger operation.
• Needle guides: Help support alignment and movement of the needle mechanism.
• Needle clamp nuts: Secure the needle within the rear control assembly.

Evolution 2024 Paint Cups & Body Components

Replacement and optional external components are also available for the Evolution 2024 platform, including paint cups, cup lids, airbrush bodies, end pieces, middle pieces, and related hardware.

Different cup capacities allow painters to configure the airbrush around the amount of paint required for a project, while replacement body and rear components provide service options for damaged or worn assemblies.

Shared Evolution 2024 & Infinity 2024 Parts

Certain components are used across more than one current-generation Harder & Steenbeck platform. Selected cups, needle clamp components, air valve parts, and other service items may be compatible with both Evolution 2024 and Infinity 2024 models.

Compatibility should always be confirmed on the individual part listing before installation, particularly when a component is shared between multiple Harder & Steenbeck airbrush families.

Choosing the Correct Evolution 2024 Replacement Part

The Evolution 2024 is a newer generation of the Evolution platform. Parts for earlier Evolution models may look similar but are not necessarily interchangeable with Evolution 2024 components.

• Confirm the model generation: Verify that the component is listed for Evolution 2024.
• Check the headset size: Match needles, nozzles, air caps, and related seals to the correct 0.28 mm or 0.45 mm configuration.
• Match the manufacturer part number: Using the product number can help distinguish between similar replacement components.
• Check shared-part compatibility: Some components may also fit Ultra 2024 or Infinity 2024, while others are specific to Evolution 2024.

Evolution Airbrushes & Harder & Steenbeck Parts

For complete Evolution airbrushes and model information, visit the Harder & Steenbeck Evolution Airbrush collection .

For parts covering additional Harder & Steenbeck models, explore the Harder & Steenbeck Airbrush Parts collection .
