Iwata HP-BCR Parts

HP-BCR Parts in This Collection

The current selection covers several areas of the HP-BCR assembly, from the front-end needle and nozzle system to internal trigger, valve, packing, and handle components.

• Needle and nozzle components: R5 needle, R5 nozzle, needle cap, and nozzle cap for servicing the front end of the airbrush.
• Air valve components: Air valve, air valve spring, and air valve guide screw for maintaining the airflow-control assembly.
• Trigger and lever parts: Main lever / trigger components for servicing the airbrush control mechanism.
• Needle control components: Needle chucking guide, chucking nut, needle spring, and needle spring guide for maintaining proper needle movement.
• Packing components: PTFE needle packing screw set for servicing the internal needle-sealing area.
• Handle component: Ergonomic handle replacement for compatible HP-BCR configurations.

Iwata HP-BCR R5 Needle & Nozzle Parts

The front-end components are among the most important parts to identify correctly when servicing an Iwata HP-BCR. The current collection includes the Iwata Needle (E5 and R5) I6171 and Iwata Nozzle (R5) I7041, along with matching cap components.

• Iwata Needle (E5 and R5) I6171
• Iwata Nozzle (R5) I7041
• Iwata Needle Cap (R5 and R3) I7011
• Iwata Nozzle Cap (R5) I7021

Check the part number and model compatibility before replacing needle or nozzle components. Parts that appear similar may be intended for different Iwata airbrush configurations.

Air Valve & Trigger Components

Air valve and trigger components control the mechanical response of the airbrush during use. If the trigger begins to feel inconsistent or an internal component becomes worn or damaged, inspect the relevant parts before replacing them.

• Iwata Air Valve Spring I0351
• Iwata Air Valve I6091
• Iwata Air Valve Guide Screw I6111
• Iwata Main Lever / Trigger I6121

Needle Chucking, Spring & Packing Parts

The rear needle-control assembly keeps the needle positioned and allows it to move correctly through the airbrush. The collection includes several components used when maintaining this area.

• Iwata Needle Chucking Guide I7157
• Iwata Needle Chucking Nut I1202
• Iwata Needle Spring I1351
• Iwata Needle Spring Guide I7701
• Iwata Needle Packing Screw Set with PTFE Packing I7251

During reassembly, avoid forcing threaded or precision components. Confirm that each part is correctly positioned before tightening or reinstalling the needle.

Iwata HP-BCR Maintenance & Part Identification

Regular cleaning and inspection can help identify worn or damaged parts before they affect normal operation. Pay particular attention to the needle, nozzle, caps, packing area, trigger mechanism, and air valve components when troubleshooting an HP-BCR.

• Clean paint-contact components after use to reduce dried-paint buildup.
• Inspect the needle tip for bending or physical damage.
• Check the nozzle and caps for dried material before replacing them.
• Inspect springs and control components if trigger movement changes.
• Check packing components if paint is reaching areas behind the intended paint path.
• Match replacement parts by model and Iwata part number whenever possible.

Current Iwata HP-BCR Replacement Components

• Iwata Air Valve Spring I0351
• Iwata Needle Chucking Guide I7157
• Iwata Needle Chucking Nut I1202
• Iwata Needle Spring I1351
• Iwata Air Valve I6091
• Iwata Air Valve Guide Screw I6111
• Iwata Main Lever / Trigger I6121
• Iwata Needle (E5 and R5) I6171
• Iwata Needle Cap (R5 and R3) I7011
• Iwata Nozzle Cap (R5) I7021
• Iwata Nozzle (R5) I7041
• Iwata Ergonomic Handle I7191
• Iwata Needle Packing Screw Set with PTFE Packing I7251
• Iwata Needle Spring Guide I7701

Related Iwata Replacement Parts

For components used with other Iwata models, browse the Iwata Airbrush Parts collection for needles, nozzles, caps, valves, springs, seals, and additional service components.

Complete Iwata airbrush models and related series can also be found in the Iwata Airbrushes collection .
